LIVE Electrical LHP840MSB 8 Module Metal Heat Pump Consumer Unit c/w 100A Main Switch, 40A Type B RCCB, 2P 40A C Curve 10kA MCB & T2 20/40kA SPD
LIVE Electrical LHP840MSB 8 Module Metal Heat Pump Consumer Unit with 100A Main Switch, 40A Type B RCCB, 40A C Curve MCB & Type 2 SPD
Product Overview
The LIVE Electrical LHP840MSB is an 8 module metal heat pump consumer unit designed to provide dedicated electrical protection for heat pump installations. Supplied pre-configured with key protective devices, it provides a convenient and professional solution for installers working with modern heat pump systems.
The consumer unit incorporates a 100A main switch together with a 40A 30mA Type B RCCB for residual current protection. A 2-pole 40A C Curve MCB with a 10kA short-circuit breaking capacity provides overcurrent and short-circuit protection, while the integrated Type 2 20/40kA surge protection device (SPD) helps safeguard connected equipment against transient overvoltages.
Combining isolation, residual current, overcurrent and surge protection within a robust metal enclosure, the LHP840MSB offers a compact and practical solution for dedicated heat pump circuits.
Key Features
- Dedicated consumer unit for heat pump protection
- 8 module metal consumer unit
- Supplied with 100A main switch
- 40A Type B RCCB
- 30mA residual current sensitivity
- 2-pole 40A C Curve MCB
- 10kA short-circuit breaking capacity
- Type 2 surge protection device (SPD)
- 20/40kA surge protection rating
- Combines isolation, residual current, overcurrent and surge protection
- Pre-configured for convenient installation
- Robust metal enclosure
Specification
- Manufacturer: LIVE Electrical
- Product Code: LHP840MSB
- Application: Heat Pump Protection
- Enclosure: Metal Consumer Unit
- Number of Modules: 8
- Main Switch: 100A
- RCCB Type: Type B
- RCCB Current Rating: 40A
- Residual Current: 30mA
- MCB: 2 Pole 40A C Curve
- MCB Breaking Capacity: 10kA
- Tripping Curve: C Curve
- Surge Protection: Type 2 SPD
- SPD Rating: 20/40kA
