Integral ILDLFR70X002 XFire Pro Maxi CCT & Wattage Switchable Fire-Rated Downlight 3.4W/5.3W 476Lm/742Lm 70-90mm Cutout Dimmable c/w White Bezel 2400K/2700K/3000K/4000K
Integral ILDLFR70X002 XFire Pro Maxi CCT & Wattage Switchable Fire-Rated LED Downlight 3.4W/5.3W 742lm Dimmable - White
The Integral XFire Pro Maxi ILDLFR70X002 is a professional-grade fire-rated LED downlight designed to combine exceptional lighting performance with flexible installation. Featuring a wider 96mm white bezel and compatibility with 70-90mm ceiling cut-outs, this versatile recessed downlight is particularly suitable for retrofit projects, refurbishment work and uneven ceilings. With switchable wattage, four colour temperature settings and a 10-year manufacturer's warranty, it provides a dependable lighting solution for residential and commercial environments.
Designed for maximum versatility, the XFire Pro Maxi features front-accessible wattage controls, allowing users to select between 3.4W (476 lumens) and 5.3W (742 lumens). Delivering an impressive luminous efficacy of 140lm/W, this energy-efficient LED downlight offers excellent brightness while helping to minimise electricity consumption.
The integrated CCT switch provides four selectable colour temperatures: 2400K Extra Warm White, 2700K Warm White, 3000K Warm White and 4000K Cool White. These settings make it easy to create the ideal lighting atmosphere for kitchens, bathrooms, bedrooms, living rooms, hallways, offices and hospitality spaces. With a high colour rendering index of CRI 90, the downlight produces natural, accurate colours for enhanced visual comfort.
Featuring dimmable functionality and a 60° beam angle, the Integral XFire Pro Maxi delivers adaptable illumination for general and task lighting applications. Its fire-rated construction supports installation in appropriate fire-rated ceiling assemblies, subject to the manufacturer's installation requirements.
Installation is made straightforward with a two-part LENNEL fast connector featuring secure latching terminals. The larger 96mm white bezel helps conceal existing ceiling openings and provides a clean, professional finish, making this downlight an excellent choice for replacing older recessed lighting fittings.
Key Features:
- Professional-quality fire-rated LED downlight from the Integral XFire Pro Maxi range.
- Wider 96mm white bezel designed for retrofit installations and uneven ceilings.
- Suitable for ceiling cut-outs ranging from 70mm to 90mm.
- Front-accessible wattage switch with selectable 3.4W and 5.3W power settings.
- Delivers 476 lumens at 3.4W or 742 lumens at 5.3W.
- High luminous efficacy of 140lm/W for energy-efficient illumination.
- Four selectable colour temperatures: 2400K, 2700K, 3000K and 4000K.
- Front-accessible CCT controls for convenient colour temperature adjustment.
- High CRI 90 colour rendering for natural and vibrant lighting.
- Dimmable functionality for adjustable brightness and improved lighting control.
- 60° beam angle for effective general and task illumination.
- Two-part LENNEL fast connector with latching terminals for quick and secure installation.
- Fire-rated construction for suitable recessed ceiling applications.
- Backed by a 10-year manufacturer's warranty.
- Ideal for residential, commercial and refurbishment lighting projects.
Technical Specifications:
- Manufacturer: Integral LED
- Product Code: ILDLFR70X002
- Product Range: XFire Pro Maxi
- Product Type: Fire-Rated LED Downlight
- Power Consumption: 3.4W / 5.3W Switchable
- Luminous Flux: 476lm / 742lm
- Luminous Efficacy: 140lm/W
- Colour Temperature: 2400K / 2700K / 3000K / 4000K
- Colour Rendering Index: CRI 90
- Beam Angle: 60°
- Fire-Rated: Yes
- Dimmable: Yes
- Cut-Out Diameter: 70-90mm
- Bezel Diameter: 96mm
- Bezel Finish: White
- Wattage Adjustment: Front-Accessible Switch
- CCT Adjustment: Front-Accessible Switch
- Connection Type: Two-Part LENNEL Fast Connector with Latching Terminals
- Installation Type: Recessed Ceiling Mounting
- Manufacturer's Warranty: 10 Years
Data Sheet:
