FuseBox MAFDD102530B 25A 1P+N Switched B Curve 10kA 30mA Type A Mini AFDD RCBO
FuseBox MAFDD102530B 25A 1P+N Switched B Curve 10kA 30mA Type A Mini AFDD RCBO
Product Description
The FuseBox MAFDD102530B is a compact 25A B Curve Mini AFDD RCBO designed to provide enhanced circuit protection for modern electrical installations. Combining arc fault detection, overcurrent protection and 30mA Type A residual current protection within a single device, it delivers three important layers of protection while making efficient use of available DIN rail space.
The MAFDD102530B analyses the circuit waveform to detect both series and parallel arc faults that could present an electrical fire risk. When a potentially hazardous arc fault is identified, the device automatically disconnects the affected circuit to help protect the installation.
Featuring a compact single-module design and 10kA short-circuit breaking capacity, this 25A Mini AFDD RCBO provides a space-saving protection solution for compatible consumer units and distribution equipment. Clear LED indication also helps installers quickly identify faults and simplify troubleshooting.
Key Features & Benefits
- 25A rated Mini AFDD RCBO
- B Curve tripping characteristic
- 1P+N switched configuration
- 10kA short-circuit breaking capacity
- 30mA Type A residual current protection
- Combines arc fault, overcurrent and residual current protection in one compact device
- Detects both series and parallel arc faults through circuit waveform analysis
- Automatically disconnects the affected circuit when a hazardous arc fault is detected
- Compact single-module construction helps maximise available DIN rail space
- DIN rail mounting for straightforward installation
- Clear LED indication assists with quick and easy fault finding
- Suitable for modern residential, commercial and other appropriate electrical installations
Product Specifications
- Brand: FuseBox
- Product Code: MAFDD102530B
- Product Type: Mini AFDD RCBO
- Rated Current: 25A
- Curve: B Curve
- Configuration: 1P+N Switched
- Breaking Capacity: 10kA
- Residual Current Rating: 30mA
- RCD Type: Type A
- Mounting: DIN Rail
