FuseBox MAFDD101630B 16A 1P+N Switched B Curve 10kA 30mA Type A Mini AFDD RCBO
FuseBox MAFDD101630B 16A 1P+N Switched B Curve 10kA 30mA Type A Mini AFDD RCBO
Product Description
The FuseBox MAFDD101630B is a compact 16A B Curve Mini AFDD RCBO designed to provide multiple levels of electrical circuit protection within a single DIN rail device. Combining arc fault detection, overcurrent protection and 30mA Type A residual current protection, it offers an effective solution for modern electrical installations where safety and space efficiency are essential.
The MAFDD101630B continuously analyses the circuit waveform to identify both series and parallel arc faults. If a potentially hazardous arc fault is detected, the device automatically disconnects the affected circuit, helping to reduce the risk of electrical fires associated with dangerous arcing conditions.
Its compact single-module construction helps maximise available DIN rail space within compatible consumer units and distribution equipment. Clear LED indication also supports quick fault identification, making inspection and troubleshooting easier for installers.
Key Features & Benefits
- 16A rated Mini AFDD RCBO
- B Curve tripping characteristic
- 1P+N switched configuration
- 10kA short-circuit breaking capacity
- 30mA Type A residual current protection
- Combines arc fault, overcurrent and residual current protection in one compact device
- Detects both series and parallel arc faults through circuit waveform analysis
- Automatically disconnects the affected circuit when a hazardous arc fault is detected
- Compact single-module design helps save valuable DIN rail space
- Clear LED indication assists with fast and straightforward fault finding
- Suitable for modern residential, commercial and other appropriate electrical installations
Product Specifications
- Brand: FuseBox
- Product Code: MAFDD101630B
- Product Type: Mini AFDD RCBO
- Rated Current: 16A
- Curve: B Curve
- Configuration: 1P+N Switched
- Breaking Capacity: 10kA
- Residual Current Rating: 30mA
- RCD Type: Type A
- Mounting: DIN Rail
