Wiska 10112338 BRACE M25 PA Polyamide Straight BraceFITTING c/w Locknut IP68, White (Pack of 10)
Wiska 10112338 BRACE M25 PA Polyamide Straight BraceFITTING with Locknut – IP68, White (Pack of 10)
Product Overview
The Wiska 10112338 BRACE® M25 PA Polyamide Straight BraceFITTING is a precision-engineered conduit fitting designed for fast, secure, and tool-free installation. Its innovative integrated TPU seal ensures a tight fit without the need for special cutting tools or additional assembly. The visible, captive seal simplifies inspection and guarantees long-lasting protection, while the 360° hinged closure provides effective strain relief and secure cable retention.
Constructed from flame-retardant polyamide (UL94-V0), this fitting offers excellent mechanical strength and heat resistance. With IP68 and IP66 ingress protection, it is fully resistant to dust and water ingress. Suitable for industrial, outdoor, and railway applications (EN 45545 compliant), the Wiska M25 BraceFITTING is supplied with an IP68-rated locknut for a safe, watertight connection.
Key Features
- Material (conduit & thread): Polyamide UL94-V0 – durable and flame-retardant
- Seal material: TPU – integrated, captive and visible for simple inspection
- Protection rating: IP68 / IP66 – dust-tight and waterproof
- Temperature range: -40°C to +100°C
- Operational compliance: EN 45545 – suitable for railway environments
- Thread type: Metric (M) with 1.5mm lead
- NW size: 23
- Ø Connection thread (D): 25mm
- Thread length (L): 14mm
- Closure diameter (VD): 42.3mm
- Internal diameter: 19mm
- Key width (SW): 36mm
- Total length (TL): 50.3mm
- Type: Straight conduit fitting
- Includes: IP68 locknut
- UL certification: UL 1696 approved
- Colour: White (RAL 9001)
- Model: EBFP-23-25-WH
- Pack size: 10 pieces
Applications
Perfect for secure and professional conduit connections in:
- Industrial machinery and automation systems
- Railway and public transport installations
- Marine and outdoor electrical enclosures
- Control cabinets and junction boxes
