LIVE Electrical CH380C Triple Pole 80A C Curve 6kA MCB

LIVE Electrical CH380C Triple Pole 80A C Curve 6kA MCB

Product Description

6kA Miniature Circuit Breakers (MCB)

Specification:

• Rated current In (A) : 80A.
• Poles: 3P.
• Rated voltage Ue(AC): 240/415V.
• Insulation volage Ui: 500V.
• Thermo-magnetic release characteristic: C
• Mechanical life: 20,000.
• Ambient temperature(with daily average ?35 ^oC?-5~+40).
• Storage temperature( ^oC)?-25~+70).
• Rated frequency: 50/60Hz.
• Rated breaking capacity(A): 6kA.
• Electrical life: 8,000.
• Contact position degree: IP20.
• Terminal Capacity : 35mm².
