FuseBox HTPNEV32SPD Horizontal TPN EV Distribution Board with 100A 4P Main Switch, 32A Bi-Directional RCBO & T2 SPD
FuseBox HTPNEV32SPD Horizontal TPN EV Distribution Board with 100A 4P Main Switch, 32A Bi-Directional RCBO & Type 2 SPD
Product Description
The FuseBox HTPNEV32SPD Horizontal TPN EV Distribution Board is a prepopulated three-phase distribution solution designed for EV charging installations where available wall space is restricted. Its horizontal format provides a compact alternative to conventional distribution boards, making it suitable for electrical cupboards, commercial premises, utility areas and other space-limited installations.
The HTPNEV32SPD is supplied with a 100A 4-pole main switch, 32A bi-directional RCBO and Type 2 surge protection device (SPD), providing essential switching, circuit protection and surge protection within one convenient enclosure.
Designed with installers in mind, the board features a spacious internal layout for straightforward cable routing, wiring and termination. A fixed horizontal fork-type busbar, removable raised DIN rail and aligned earth and neutral bars provide improved accessibility and help achieve a neat and efficient installation.
The enclosure is manufactured from robust 1.2mm steel with a durable RAL9001 powder-coated finish. Top and bottom gland plates provide flexible cable entry, while the reversible door can be fitted to either side to suit the installation. A coin-slot door lock provides secure and convenient access.
Key Features
- Horizontal TPN EV distribution board
- Prepopulated configuration for EV charging applications
- Supplied with 100A 4-pole main switch
- 32A bi-directional RCBO
- Type 2 surge protection device (SPD)
- Horizontal design for space-restricted installations
- Fixed horizontal fork-type busbar
- Spacious internal layout for easier cable routing and termination
- Removable and raised DIN rail for improved wiring access
- Aligned earth and neutral bars for faster and tidier wiring
- Coin-slot door lock for secure and convenient access
- Top and bottom gland plates for flexible cable entry
- No knockouts for greater flexibility when glanding
- Reversible door can be fitted to either side
- Easily removable devices
- Robust 1.2mm steel enclosure
- Surface-mounted installation
- IP3X rated enclosure
- 16kA short-circuit rating
Technical Specifications
- Manufacturer: FuseBox
- Part Number: HTPNEV32SPD
- Application: EV Distribution
- Configuration: Prepopulated
- Main Switch Rating: 100A
- Main Switch: 4 Pole
- RCBO Rating: 32A
- RCBO Type: Bi-Directional
- Surge Protection: Type 2 SPD
- Rated Voltage: 400V
- Frequency: 50Hz
- Short-Circuit Rating: 16kA
- Busbar Type: Fork
- IP Rating: IP3X
- Mounting Type: Surface
- Material: Steel
- Enclosure Thickness: 1.2mm
- Finish: RAL9001 powder coated
- Cable Entry Points: Top and bottom gland plates
- Dimensions (H x W x D): 470 x 295 x 113mm
- Standard: EN 61439-15
